3W: R635-700mW/G525-800mW/B450-1.5W

4W: R635-1.2W/G525-1W/ B450-2W

5W: R635-1.2W/G525-1.4W/ B450-3W

Rated Voltage:  AC100~240V 50/60Hz;≤100W

Scanner: 3W25K+, 4W, 5W30KPPSfast scanning system, scan angle:max±30°;Input signal:±5V;

Modulation: analog

Beam diameter and divergence:  3*6.5mm;1.5mrad

Control mode: sound, auto, master-slave, DMX512(5/17/18/27/52CH), SD card, ILDA

Control Interface: 3 pin DMX512, 25DB ILDA

Demonstration effect: built-in 160 pattern,SD card unlimited storage.

DMX effect:  double pattern mode,and with the function of unique blanking,strobe, rotation, movement, zoom, write in,speed and color etc.

Control technology:  ①RDM data bidirectional transmission ② SD card online upgrade ③temperature control system ④DMX512 upgrade

Operating requirement:  dry, less dust, 0~35℃(environmental temperature),will reduce the attenuation of the diode and extend the life of the light.

Application:  disco, club, medium indoor venue, theatre, etc.

Size: 400*370*475mm(2 in 1)

Net weight: 14.5kg(2 in 1)

Gross weight: 18kg(2 in 1)
