2W: R635nm-500mW/G525nm-400mW/B450-1.2W

3W: R635nm-700mW/G525nm-800mW/B450-1.5W

5W: R635nm-1.2W/G525nm-1.4W/B450nm-3W

Rated voltage and power：AC100~240V 50/60Hz;≤100W

Scanner: 20kpps Scan angle: max±25°;Input signal:±5V;Linearity distortion<2%

Modulation: analog

Beam diameter and divergence: 3*6.5mm;1.5mrad

Control mode: music(blackout)/automatic/master-slave/DMX512(5/17/18/27/52CH)

Control Interface: 3 pin DMX512, DB25 ILDA

Connector: (Pangplin (USA), moncha,ect)

Demonstration effect: built-in 160pattern (7groups×20cues) with 20 groups of animation（1group×20cues）

DMX effect: pattern can output the function of unique blanking,strobe,rotation,movement,zoom, write in,speed and color etc.

Application: indoor small venue

Package: carton box

Box size(L*H*W): 370*320*430mm(2 in 1 )

Gross weight: 10.2kg
